ENGINE
2.22
22. Installthe kick crank assembly ontothe kick shaft.
23. Carefully install the engine into the chassis. Secure
the engine with the engine mounting bolts.
Engine Mounting Bolts
24. Connect the oil cable to the oil pump. Tighten the
cable.
25. Install the fan cover.
26. Connect the exhaust pipe to the engine and frame
mounting areas.
27. Install the air box and carburetor.
Air Box and Carburetor
28. Install the body panels.
