Polaris Scrambler 50

BODY/STEERING/SUSPENSION
4.10
SCRAMBLER FRONT AND
REAR CAB INSTALLA
TION
1. Install the bumper to the frame and tighten
mounting bolts to specification.
Front Bumper Mounting
Bolt Torque:
103 in.lbs. (12 Nm)
2. There are three (3) mounting positions for the
front and rear cab to the frame. The front cab is
mounted on positions 1 and 2. The rear cab is
mounted on position 3.
1
2
3
3. Install the front and rear cab to the frame and
tighten the mounting bolts to specification.
Front Cab Assy.
Rear Cab Assy.
Cab Mounting Bolt Torque:
103 in.lbs. (12 Nm)
4. The front cab mounts to the front bracket of the
frame.
SPORTSMAN FRONT AND
REAR CAB INSTALLA
TION
1. Install the bumper to the frame and tighten
mounting bolts to specification.
