40
FEATURES AND CONTROLS
Hitches
See the specification section beginning on page 148 for hitch weight
capacities.
Do not tow a vehicle or a trailer with this vehicle unless all instructions have
been followed. See pages 80-82.
Whenever the vehicle is towing, always stay clear of the area between the
vehicle and the towed object.
Rear Hitch (Zugmachine)
Use the rear hitch for towing a trailer. See pages 80-82 for procedures.
Rear Hitch Certification Label (Zugmachine)
The hitch certification label is located near the hitch on models
equipped with a factory-installed rear hitch.
Rear Hitch Specifications
Material S355J2+N
Fasteners Metal pin with security cotter pin
Weld Length and Positions 4 mm fillet, all around
Maximum Vertical Load 75 kg applied on coupling point
Maximum Towable Mass 750 kg
Approval # E9-55R-01 6121
