93
MAINTENANCE AND LUBRICATION
Lights
Lower Headlamp Removal / Installation
1. Turn the back of the headlight harness (1) in
a clockwise direction.
2. Pull the harness assembly out from the
headlight assembly.
3. Remove the headlamp and install
the new headlamp.
4. Install the new headlamp and harness
assembly into the headlight assembly. Turn the
headlight harness counterclockwise to secure.
Taillight /Brakelight Lamp Replacement
1. Remove the taillight lens
cover mounting screws (1).
2. Remove the lens cover (2)
and gasket.
3. Remove the lamp (3).
4. Apply dielectric grease to the
socket and install the new
lamp.
5. Test the t aillight/brakelight.
6. Reinstall the gasket and lens cover.
1
1
2
3
