Polaris ToyotaLUXX Installation Manual

1300 555 514 7
Wiring Diagram: Reverse Camera
Head
REVERSE
TRIGGER
REVERSE FOUND IN
ORIGINAL HARNESS
(COLOUR MIGHT DIFFER
FROM BRANDS AND
MODELS)
Acc+
CUT AND TAPE OFF WIRES AS NOT
NEEDED IN THIS SET UP AS NOT
NEEDED IN THIS SETUP.
RCA PLUGS INTO CAMERA
INPUT FOUND ON HEAD
UNIT
CONSTANT CAMERA AND TRIGGER
DIAGRAM 1
Head
REVERSE TRIGGER
POWER FROM REVERSE LIGHTS
RCA PLUGS INTO CAMERA
INPUT FOUND ON HEAD UNIT
RCA CAMERA WITH REVERSE TRIGGER ONLY
DIAGRAM 2
