REVERSE TRIGGER WIRE
Acc+
CUT AND
TAPE OFF
WIRES AS
NOT
NEEDED
IN THIS
SET UP
RCA PLUGS
INTO CAMERA
INPUT FOUND
IF NO REVERSE TRIGGER IS FOUND PLEASE FOLLOW THE SECOND DIAGRAM, IF YOU WOULD LIKE A CONSTANT CAMERA AS
WELL, A TRIGGER MUST BE BROUGHT FROM REVERSE LIGHT
(POWER TO
CAMERA)
DIAGRAM 3
Wiring Diagram: Reverse Camera (cont.)
