A. Summary of Dip Switch Settings
ORP Switches Description
(located behind
the ORP display)
1 Always on
2 Always on
3 Feed Cycle Setting
4 Feed Cycle Setting
5 Delay Cycle Setting
6 Delay Cycle Setting
7 OFF = Pool Mode (longer feed and delay
cycles for a larger body of water)
ON = Spa Mode (shorter feed and delay
cycles for a smaller body of water)
8 OFF = Feed Cycle in Seconds
ON = Feed Cycle in Minutes
9 ON = Alert for low ORP
10 OFF = Timed Feed
ON = Continuous Feed
pH Switches Description
(located behind
the pH display)
1 ON = No ORP feed if the pH is out of range
OFF = ORP feed regardless of the pH
2 ON = No ORP feed while the pH is feeding
OFF = ORP and pH can feed simultaneously
3 Feed Cycle Setting
4 Feed Cycle Setting
5 Delay Cycle Setting
6 Delay Cycle Setting
7 OFF = Feed Cycle in Seconds
ON = Feed Cycle in Minutes
8 OFF = Base Feed
ON = Acid Feed
9 ON = Alert for high and low pH
10 OFF = Timed Feed
ON = Continuous Feed
25
