Delay Cycle Switch Switch Delay Cycle Switch Switch
#5 #6 #5 #6
2 Minutes OFF ON 1 Minutes ON ON
5 Minutes OFF OFF 2 Minutes OFF ON
10 Minutes ON OFF 5 Minutes OFF OFF
20 Minutes ON ON 10 Minutes ON OFF
E. Watermatic G-1000, G-1000A or G-7500 Feeder
These feeders can only operate with a short feed cycle followed
by a delay; continuous or long feed cycles damage the feeders.
1. Timed Feed Mode = ORP and pH Switch #10 are OFF
2. Feed Cycle in Seconds = ORP Switch #8 is OFF
pH Switch #7 is OFF
3. Pool Mode = ORP Switch #7 is OFF
Spa Mode = ORP Switch #7 is ON
4. Choose your desired feed and delay cycle times from the fol-
lowing options.
Recommended Settings
ORP SWITCHES
Feed Cycle Switch Switch Delay Cycle Switch Switch
#3 #4 #5 #6
4.8 Seconds ON OFF 10 Minutes ON OFF
pH SWITCHES
Feed Cycle Switch Switch Delay Cycle Switch Switch
#3 #4 #5 #6
4.8 Seconds OFF ON 10 Minutes ON OFF
Optional Settings
ORP SWITCHES
Pool Mode (#7 OFF) Spa Mode (#7 ON)
Feed Cycle Switch Switch Feed Cycle Switch Switch
#3 #4 #3 #4
4.8 Seconds ON OFF .6 Seconds OFF OFF
7.2 Seconds OFF OFF 1.2 Seconds ON OFF
9.6 Seconds ON ON 2.4 Seconds OFF ON
14 Seconds OFF ON 3.6 Seconds ON ON
29
