Delay Cycle Switch Switch Delay Cycle Switch Switch
#5 #6 #5 #6
5 Minutes ON ON 2 Minutes ON OFF
10 Minutes ON OFF 5 Minutes OFF OFF
20 Minutes OFF OFF 10 Minutes OFF ON
30 Minutes OFF ON 15 Minutes ON ON
D. Sensor Located After Sanitizer Introduction
If you are using the controller with an installation where the sen-
sor is located downstream of the introduction of the sanitizer,
there is a potential for the sensor readings to be inaccurate.
Since this installation is generally associated with sanitizer
tablets, which dissolve slowly, it is better to have a long feed
cycle followed by a delay that allows the sanitizer to circulate
past the sensor. This will ensure proper readings from the sen-
sor.
1. Timed Feed Mode = ORP Switch #10 is OFF
2. Feed Cycle in Minutes = ORP Switch #8 is ON
3. Pool Mode = ORP Switch #7 is OFF
Spa Mode = ORP Switch #7 is ON
4. Choose your desired feed and delay cycle times from the fol-
lowing options.
Recommended Settings
ORP SWITCHES ONLY
Feed Cycle Switch Switch Delay Cycle Switch Switch
#3 #4 #5 #6
12 Minutes OFF ON 5 Minutes OFF OFF
Optional Settings
ORP SWITCHES ONLY
Pool Mode (#7 OFF) Spa Mode (#7 ON)
Feed Cycle Switch Switch Feed Cycle Switch Switch
#3 #4 #3 #4
12 Minutes OFF ON 2 Minutes OFF ON
16 Minutes OFF OFF 4 Minutes OFF OFF
24 Minutes ON ON 6 Minutes ON ON
32 Minutes ON OFF 8 Minutes ON OFF
28
