Figure Description Page
- Drive Assembly components 61
39 Removing parts from Gear Drive Cover 62
40 Releasing Springs and Drive Cover detents 63
41 Removing Gear Drive Cover 64
42 Removing parts from Gear Drive 64
43 Removing Counter, Gears & Pick 65
44 Removing S1 Slider and S5 Actuator 65
45 Replacing Actuator and Slider Assy 66
46 Verifying Slider-Switch contact relationship 66
47 Gear placement guide 67
48 Replacing Door Pawl and Spring 67
49 Replacing Counter 68
50 Replacing Pick & Return Spring 68
51 Replacing the Timing Gear 69
52 Setting Counter and Pawl Springs 69
53 Reconnecting wiring to Contacts 70
54 Removing Spread System from Door 71
(SECTION 6 Camera Testing with the Star Tester)
1 Graywall setup 87
2 Installing modified Strobe Fixture 12657B 88
3 Aligning Camera on Horn with Tester window 89
4 Installing risers under leveling legs 90
5 Test setup and Horn Riser position 91
6 Star Tester Controls & Indicators 94
7 Setup for 636 Graywall Test 98
8 Removing 636 Front Plate 100
9 Adjusting Blade Spring 100
10 Replacing Front Plate w/modified Front Plate 101
11 Adjusting Ambient Calibration Disc 101
12 Adjusting IR Calibration Wedge 102
(SECTION 7 Camera Testing with the B-600 Tester)
1 B-600 Tester and Model B Light Source 108
2 Camera on Horn, ready for testing 111
3 Removing Front Plate/Lens Panel 115
4 Adjusting Opening Blade Spring 115
5 Replacing Front Plate w/modified Front Plate 116
6 Adjusting IR Calibration Wedge 116
7 Adjusting Ambient Calibration Disc 117
iv
