PROBLEM PROBABLE CAUSE CORRECTIVE ACTION
High Current Drain NOTE: First determine whether problem is with strobe or camera.
Replace strobe with known good test strobe. If operation is
OK with test strobe, problem is in original strobe which must be
replaced. If operation reveals high current drain with good test
strobe, problem is in camera. Continue below:
1. Switch contacts on block 1. Re-form contacts or
are distorted. replace contact support
block as necessary.
2. Contact support block 2. Replace contact support
defective. block.
3. Flex circuit defective. 3. Replace flex circuit.
Strobe Failures: NOTE: First determine whether the problem is with the
No Flash strobe or the camera. Replace the strobe with a
No Charge known good test strobe. If operation is OK with
LED stays on test strobe, the problem is with the original
strobe which must be replaced. If operation
reveals problems with good test strobe, problem
is in camera. Continue below:
1. SlO button and movable 1. Assemble camera
SlO contact interface properly.
incorrect.
2. SlO contact distorted. 2. Re-form contact.
3. SlO jumper wire not 3. Install jumper wire
trapped in movable properly.
contact or wire block
properly.
4. Bare (+) wire not 4. Install (+) wire
trapped in fixed SlO properly.
contact properly.
5. Flex circuit not 5. Install flex properly.
installed into PC board
properly.
NOTE: Use meter to check continuity
between points.
82
