PROBLEM PROBABLE CAUSE CORRECTIVE ACTION
LED does not light NOTE: If strobe does not function,
see Strobe Failures.
1. LED shorted at PC board. 1. Correct short.
2. LED not installed 2. Install LED properly.
properly on PC board.
3. LED defective. 3. Replace LED/PC board.
4. Flex circuit defective. 4. Replace flex.
5. Strobe PC board 5. Replace strobe.
defective.
6. Film battery dead/film 6. Insert fresh film pack.
pack absent.
Light leaks in 1. Light seal on cone 1. Install cone light
picture missing. seal.
2. Baseblock photographic 2. Install photographic
tape light seal missing. tape on baseblock.
3. Mirror cover light seal 3. Install mirror cover
not positioned properly. light seal properly.
4. Film pack spring 4. Replace pack spring.
defective.
Close-Up Lens Does 1. Lens return spring 1. Install spring
Not Function missing or out of properly.
Properly position.
2. Shuttle binding in 2. Install shuttle
apron guide rails. properly.
3. Close-up lens not 3. Install lens
riding in apron properly.
rails properly.
4. Return spring tab 4. Replace lens panel.
broken.
83
