System Connections
7
C
ONNECT TO A TV
Before connecting the system, be sure to turn off the power source of this unit and other devices.
There are three kinds of video outputs in this unit: component video, S-video, and composite video. You can select
one of the available video inputs of the TV and make the connection.
In terms of picture quality, the component video is the best, followed by S-video, then composite video.
When connecting the audio output of the unit to the TV, connect the left and right audio outputs to the TV audio inputs
of the same group as the connected video inputs.
Component video and S-video cables not included.
•
•
•
•
