- 13 -
Rechargeable Battery Description
Charging the Battery Pack
The battery must be attached to the unit to charge it. Plug the Power Adapter into the
unit’s DC 9.5V IN Jack, which is located on left of the unit. Plug the other end of the
Power Cord into a wall Outlet.
Detaching the Battery Pack
If the unit is not going to be used for long periods of time, the Battery Pack should be
detached.
Make sure the power is turned OFF before detaching the Battery Pack. After detaching
the battery pack, take care when handling the unit.
1. Place the unit on a soft and smooth surface with its back cover up to avoid
scratching the screen.
2. Press the button located on the backside of the unit to unlock the battery pack and
while pressing the button pull the battery pack out from the unit.
NOTE: When attaching or detaching the battery pack, make sure to protect the LCD
screen.
