- 15 -
System Connections
Connecting to an Amplifier
The unit can be connected to an amplifier. Plug the supplied A/V cable into the audio jack
on the left side of the unit and plug the other end into an audio input on the amplifier.
Please refer to the equipment’s manual of your amplifier before connecting. Switch the
TV/AV to TV.
In TV mode, it output analog audio signal.
Connecting to an External AV Signal Source
The unit supports AV input function, it can be connected to the external AV signal source,
such as a DVD, follow the below figure to connect and switch the TV/AV to AV.
