Impulse Series Camera User Guide
4
The camera
Impulse
Impulse AF
Front View Back View
FGH
Front View Back View
A-Electronic flash (shown raised).
A1 - Self-timer button (Impulse AF only).
A2 -Self-timer indicator (Impulse AF only).
B - Single -element, 113mm lens (protected by a
lens cover when the flash is lowered).
C - Photocell (measures light from the scene.
D -Lighten/darken control.
E - Film exit slot.
E1 -Sonar rangefinder (Impulse AF only).
F - Film shade (protects the picture from light as it
exits the camera).
G -Film door.
H - Film door latch.
I - Picture counter (counts down to show how many
pictures are left in the film pack).
J -Green ready light (shows the flash is ready to
fire).
J1 -Flash status light (red when the flash is charging;
green when flash is ready to fire; Impulse AF
only).
K -Shutter button.
L -Viewfinder.
M -Tripod socket (underneath the camera).
N -Neckstrap connector.
A
B
C
D
E
FGH
I
J
K
L
MN
A
B
C
D
E
I
J1
K
L
MN
A1
A2
E1
