• Zumo chassis kit [http://www.pololu.com/catalog/
product/1418], which includes:
◦ Zumo chassis main body
◦ 1/16″ black acrylic mounting plate (not used
with the Zumo Shield)
◦ Two drive sprockets
◦ Two idler sprockets
◦ Two 22-tooth silicone tracks
◦ Two shoulder bolts with washers and M3 nuts
◦ Four 1/4″ #2-56 screws and nuts
◦ Battery terminals
• Basic sumo blade for Zumo chassis
[http://www.pololu.com/catalog/product/1410]
You will receive the black acrylic spacer and mounting plates with protective paper masking on
both sides. You can peel this masking off to expose the acrylic surface, or you can leave it on to
increase the thickness of the plates.
The shield and chassis kit include extra parts like jumper wires, screws, nuts, and washers, so do
not be concerned if you have some leftover hardware after assembling your Zumo.
