Fully assembled Zumo chassis
with assembled Zumo Shield.
1.a. Contacting Pololu
We would be delighted to hear from you about your experiences with the
Zumo Shield for Arduino [http://www.pololu.com/catalog/product/2504] or
Zumo robot kit for Arduino [http://www.pololu.com/catalog/product/2505]. If
you need technical support or have any feedback you would like to share,
you can contact us [http://www.pololu.com/contact] directly or post on our
forum [http://forum.pololu.com/viewforum.php?f=29]. Tell us what we did well,
what we could improve, what you would like to see in the future, or
anything else you would like to say!
1.b. Included components
The Zumo Shield is available by itself [http://www.pololu.com/catalog/product/
2504] or as part of a Zumo robot kit for Arduino
[http://www.pololu.com/catalog/product/2505] that also includes a Zumo
chassis [http://www.pololu.com/catalog/product/1418] and a stainless steel Zumo blade [http://www.pololu.com/catalog/
product/1410].
Zumo Shield
The shield itself comes with the following
components:
• right-angle slide switch
• two pushbuttons [http://www.pololu.com/catalog/
product/1400]
• buzzer
• 2-pin battery-charging header
[http://www.pololu.com/catalog/product/1012]
• three jumper wires (for soldering motors to the
chassis)
• 40-pin 0.1″ straight breakaway male header
[http://www.pololu.com/catalog/product/965]
• two blue shorting blocks
[http://www.pololu.com/catalog/product/968]
• two 5/16″ #2-56 machine screws (to be used instead of the 1/4″ screws included with the chassis kit if you
attach a Zumo blade)
• 1/16″ black acrylic spacer plate (two pieces)
Zumo Robot Kit for Arduino
In addition to the shield and its included hardware, the Zumo robot kit for Arduino also includes these
components:
