Polon-Alfa EKS-6022 - EKS-6000 Technical Specifications

IK-E337-001 7
2. Technical data
I/O element type
EKS-6040
EKS-6004
EKS-6022
EKS-6044
EKS-6202
EKS-6400
Detection line supply voltage
16.5 – 24.6 V
Current consumption from detection line
< 210 µA
< 240 µA
< 220 µA
< 240 µA
< 250 µA
< 230 µA
Detection line short-citcuit insulator
yes
Configuration of I/O element
from control panel
Number of outputs
0
4
2
4
2
0
Supply voltage of the controlled device
6 – 220 VDC
230 VAC
Relay control output
potential-free, supervised, change-over contact, max. current 2 A,
max. voltage 230 VAC / 220 VDC, max. power 62.5 VA / 60 W
Continuity monitoring of the cable connected to the control
output
yes (jumper on printed circuit board)
closed, opened
Control output safe state
no change, not triggered, triggered
Current consumption in the continuity monitoring circuit of the
cable connected to the control output
< 200 µA (6 – 220 VDC)
< 370 µA
Number of inputs
4 IN
0
2 IN
4 IN
2 IN HV
4 IN HV
Input function
(IN) control or alarm
(IN HV) control
Input initialization
(IN) potential-free, NO or NC contact
(IN HV) live contact
Control of the cable connected to the input
(IN) close, open
(IN HV) none
Input line capacity
< 12 nF (about 100 m of YnTKSY cable, 1×2×0.8 mm)
Cable entry:
- Detection line cable gland
- Low-voltage input cable gland
- High-voltage output/input cable gland
2 × M12
4 × M12
–
2 × M12
4 × M12
–
–
–
4 × M16
2 × M16
4 × M16
4 × M16
4 × M16
Conductor permissible cross-section
up to 2.5 mm
2
Dimensions
Figure 1
Figure 2
Figure 3
Figure 4
Figure 2
Figure 2
Weight
< 0.5 kg
Operating temperature
–40 to +85°C
Climatic category
40/085/04
Permissible relative humidity
to 95% at 40°C
Electrical strength of insulation
1500 V
Protection class
IP 66
Enclosure material and colour
polycarbonate (PC), grey
