1
PRESSURIZED POND FILTER
CARE AND OPERATING INSTRUCTIONS
ZG400 revG 10/20
MODELS ITEM #
No UV With UV
120V 230V
2700
05610 05615 05617
5500
05620 05625 05627
8000
05630 05635 05637
16000
05640 05645

Table of Contents

Questions and Answers

  • M
    Michael SmithAug 14, 2025
    How to fix sluggish filter output in Pondmaster Water Filtration Systems?
    • M
      Megan ThomasAug 14, 2025
      If your Pondmaster Water Filtration System's filter output is sluggish, several factors could be at play. The filter pad might be clogged, necessitating removal, rinsing, and replacement. Also, backwash the filter. The pump intake could be obstructed, or the pump might be undersized or in need of maintenance; inspect the pump, clear any debris, and consider using a Pump Bag to prevent future blockages. The discharge could also be clogged, requiring you to remove any blockages. Finally, the tubing might be too small, too long, or kinked; test the filter with the valve in the #3 Circulate (Bypass) position to assess your hose and pump setup.
  • K
    kennethhowardAug 18, 2025
    Why is the pressure gauge in the yellow zone on my Pondmaster Water Filtration Systems?
    • J
      jramirezAug 18, 2025
      If the pressure gauge pointer on your Pondmaster Water Filtration System is in the yellow zone, it could be due to several reasons. Debris may have accumulated too thickly, requiring you to remove and rinse the filter pad and backwash the system. If necessary, manually stir up the Bio-Media or use air turbulence before backwashing, checking weekly. Alternatively, the pump might be oversized, in which case you should replace it with a recommended pump or split the water flow between the pump and filter intake using a Valved Bypass. The setup might also be causing excessive back pressure, so test the filter with the valve positioned to #3 Circulate position. Lastly, the outlet could be clogged; check for obstructions and clear the outlet.
  • M
    Mary LyonsAug 20, 2025
    What to do if Pondmaster Clearguard 2700 drum is leaking?
    • J
      johnsonmelanieAug 21, 2025
      If your Pondmaster Water Filtration System's filter drum is leaking at the perimeter, it could be due to a few reasons. The O-Ring or Gasket might be missing, twisted, dirty, or not lubricated. Turn off the pump, open the filter, and remove, clean, re-seat, and lubricate the O-Ring/gasket. Attach the cover, checking the alignment of the tab & slot, and thoroughly tighten the clamp knob. High water pressure, possibly from an oversized pump, may also be the cause. Install a Valved Bypass to redirect excessive water pressure buildup, diverting water directly to your waterfall. Lastly, the setup might be creating back pressure due to the hose configuration; redo the setup to eliminate back pressure on the outlet port of the filter.
  • D
    david39Aug 25, 2025
    Why UV does not light on Pondmaster Clearguard 2700?
    • S
      Susan VargasAug 25, 2025
      If the UV light on your Pondmaster Water Filtration System isn't lighting, first check for power supply issues by examining the GFCI and confirming all plugged connections. It could also be due to improper installation sequence; always have the unit completely installed before powering up the UV, as it won't light if plugged in first and then assembled. Another potential cause is the bulb dislodging from the socket; turn off the pump, open the UV, and reattach the bulb before reassembling and applying power.
  • J
    Jeffrey FigueroaAug 27, 2025
    What to do if water flows from incorrect port on Pondmaster Water Filtration Systems?
    • K
      Kristin ChavezAug 28, 2025
      If water is flowing from the incorrect port or you're experiencing difficulty rotating the handle when fully depressed on your Pondmaster Water Filtration System, the silicone gasket may be damaged or dislodged. Replace the diverter assembly to resolve this issue.
  • G
    garycarsonAug 30, 2025
    Why is the pressure gauge pointer in the yellow zone on my Pondmaster Clearguard 2700?
    • A
      Austin MoodyAug 31, 2025
      If the pressure gauge pointer on your Pondmaster Water Filtration System is in the yellow zone, it could be due to several reasons. The debris may have grown too thick, in which case you should remove and rinse the filter pad and backwash the system. If necessary, manually stir up the bio-media or use air turbulence before backwashing. Check weekly. Another cause may be that the pump is oversized. Replace it with a recommended pump or split the water flow between the pump and filter intake using a valved bypass. Also, the set-up may cause excessive back pressure. Test the filter with the valve positioned to the circulate position. If it is still slow, make adjustments to the setup. Finally, the outlet may be clogged. Check for obstructions and clear the outlet.
  • E
    Elizabeth DurhamSep 3, 2025
    What to do if Pondmaster Clearguard 2700 Water Filtration Systems drum is leaking at perimeter?
    • G
      George BookerSep 4, 2025
      If your Pondmaster Water Filtration System's filter drum is leaking at the perimeter, it might be because the O-ring or gasket is missing, twisted, dirty, or wasn't lubricated. To resolve this, turn off the pump, open the filter, and remove the O-ring/gasket. Clean, re-seat, and lubricate it. Then, reattach the cover, ensuring the alignment of the tab and slot, and thoroughly tighten the clamp knob. Another reason could be that the water pressure is too high because the pump is too large. Install a valved bypass to redirect excessive water pressure buildup, diverting water directly to your waterfall. Finally, the set-up might be creating back pressure due to the hose configuration. Redo the set-up to eliminate back pressure on the outlet port of the filter.
  • Q
    qpotterSep 6, 2025
    Why is water flowing from the incorrect port in Pondmaster Water Filtration Systems?
    • J
      Jonathan WardSep 6, 2025
      If water is flowing from the incorrect port or if you're having difficulty rotating the handle when fully depressed on your Pondmaster Water Filtration System, the silicone gasket may be damaged or dislodged. The solution is to replace the diverter assembly.
  • K
    kathleenbrownSep 10, 2025
    How to troubleshoot UV light not working on Pondmaster Water Filtration Systems?
    • F
      fwolfSep 10, 2025
      If the UV light on your Pondmaster Water Filtration System isn't lighting, first check the GFCI and confirm all plugged connections to address any power supply issues. Also, ensure the unit was completely installed before powering up the UV, as it won't light if plugged in before assembly. Lastly, the bulb may have dislodged from its socket. Turn off the pump, open the UV unit, and reattach the bulb, then reassemble and apply power.

Pondmaster Clearguard 2700 Specifications

General IconGeneral
Maximum Pond Size2700 gallons
Maximum Flow Rate2700 GPH
Flow Rate2700 GPH
Recommended Pond SizeUp to 2700 gallons
Inlet/Outlet Size1 inch
Filter MediaFoam pads
