6
1.1. TECHNICAL SPECIFICATION
1880
1110
1330
145
400
500
110
695
605
430
185
75
750
SPA MARINA dimensions:
- length: 188 cm
- width: 133 cm
- depth: 70 cm
- height: 75 cm
Capacity: 580 litres
Weight:
150kg (without water and housing)
Material and construction:
acrylic strengthened by laminated polyester
on an aluminum frame
Voltage: 230 V, 4,5 kW
Nominal power:
- 2 kW electric heater
- 1,5 HP hydromassage pump
- axial blower with air heater 1.1kW (0,8 kW blower and 0,3 kW air heater)
Power cable: 3 x 2,5 mm²
Maximum number of people in the bath: 3
Water:
The water should come from the water system and be properly purifi ed and disinfected accordingly
to DIN-19643/97 as well SIA-173.
Well water is inadvisable, unless it has special certifi cates in compliance with current norms.
System ANTIFROST czyli Smart Winter Mode
Most important task of SPA electronic system is holding temperature of water within the range bet-
ween 15 to 40
0
C. However electronic system has additional feature - winter operation mode (Anti-
frost/Smart Winter mode) which protects piping against frozing.
PCB integrated temperature sensor continously controls air temperature which surronds electronic
system. If air temperature decrease below 15
0
C electronic system starts winter mode. In this mode
system switches on every pump for 1 minute (one by one). Frequency of pumps operations is con-
nected with surrounding temperature and is presented in the table below. Water heater works inde-
pendently of air temperature sensor, it depend only of water temperature sensor.
Temperatura
0
C Operating frequency (min)
12 < t ≤ 15 120
9 < t ≤ 12 60
6 < t ≤ 930
t ≤ 615
• Operation mode ANTIFROST system is marked by ICE symbol on the LCD screen.
• Stand by mode doesn’t affect on ANTIFROST system operations.
• after activating the ANTIFROST system all functions beside water heating are not used.
• All these functions are not available until ICE symbol disappered. Is possible to take a bath but use
