1.1. Technical specifi cations
1765
1580
660
600
260
440
355
550
805
860 ± 10
930 ± 10
SPA Victoria dimensions:
- width: 1765 mm,
- depth: 765 mm,
- height: 870 mm +/- 20 mm.
Capacity: 800 l.
Weight:
~ 275 kg (without water).
Material and construction:
Sanitary acrylic strengthened by laminated
polyester, insulated with polyurethane foam,
on an aluminium frame.
Supply voltage:
230V~, 5 kW
3 ~ 400 V as option
Nominal power:
- 2 kW electric heater (6 kW as option)
- 2,0 HP (1,5 kW) hydromassage pump,
- 1.2 kW axial blower.
Power cable: 3 x 2,5 mm².
Fig. 1-1. Dimensions of SPA VICTORIA
Maximum number of people in the bath: 4.
Water:
The water should come from the water system and be properly purifi ed and disinfected. Well water
is inadvisable, unless it has special certifi cates in compliance with current norms.
ANTIFROST System / Smart Winter Mode
Most important task of SPA electronic system is holding temperature of water within the range bet-
ween 15 to 40
0
C. However electronic system has additional feature - winter operation mode (Anti-
frost/Smart Winter mode) which protects piping against frozing.
PCB integrated temperature sensor continously controls air temperature which surronds electronic
system. If air temperature decrease below 15
0
C electronic system starts winter mode. In this mode
system switches on every pump for 1 minute (one by one). Frequency of pumps operations is con-
nected with surrounding temperature and is presented in the table below. Water heater works inde-
pendently of air temperature sensor, it depend only of water temperature sensor.
Temperatura
0
C Operating frequency (min)
12 < t ≤ 15 120
9 < t ≤ 12 60
6 < t ≤ 930
t ≤ 615
• Operation mode ANTIFROST system is marked by ICE symbol on the LCD screen.
• Stand by mode doesn’t affect on ANTIFROST system operations.
• After activating the ANTIFROST system all functions beside water heating are not used.
