11
Step 4
Pass the 2 32/50 hose clamps around the
corrugated pipe, then install it so that it faces
the connection between the lter body and
the cover, as shown in the following gure.
Then tighten the hose clamps with a screw-
driver.
CAUTION: EXCESSIVE TIGHTENING
CAN DAMAGE THE HOSE.
Step 5
Install the 32/38 ttings on the cover as well
as on the ltration shell, check the provided
seal joints are in place and in good condition,
and tighten them by hand.
