13
EN
I. Introduction
The robotic pool cleaner RED PANTHER is a new type of rechargeable automatic cleaning equipment with
the function of self-beaching when the battery is running out.
Please read this manual carefully before use so that you can use it correctly.
II. Specifications
Working voltage: 12.6V
Power: 50W
Battery life: Max. 120min
Rated input voltage of adapter: AC 100V-240V
Input power of adapter: 47Hz-63Hz
Rated output current of adapter: 1.8A
Rated output voltage of adapter: 12.6V
Charging time: 5-6h
Battery capacity: 6600mAh
Max. cleaning surface: 100 m²
Filter capacity: appr. 10 m³/h
Filter capability: 180μm
Climbing slope: 15°
Pool water temperature: 10°C-35°C
Moving speed: appr. 16 m/min
IP Grade: IPX8 (main body)
Charging environment temperature: 0-45°C
Max. water depth: 2.0m
Size: 400 x 360 x 270 mm (LxWxH)
Weight: 5.5 kg
Storage condition:
Short term (less than 1 month): -20°C - 60°C ≤75%RH
Medium term (less than 3 months): -20°C - 45°C ≤75%RH
Long term (more than 3 months): -20°C - 20°C ≤75%RH
Floating handle
Filter tray
Top cover
Chassis
Brush
Charger plug, ON/OFF knob
and indicator light
Charger
