To Next PageTo Next PageWhy is my Port A Cool Freezer pump so loud?
If your Port A Cool Freezer pump makes a loud noise while running, it could be due to pump bearings, in which case you should replace the pump. Another possibility is an object in the impeller housing; clear the object.
How to fix a Port A Cool Freezer fan motor that won't run and makes no sound?
If the fan motor of your Port A Cool Freezer doesn't run and makes no sound, the issue might be with the power cord, extension cord, switches, or circuit breaker. Try reconnecting the power or extension cord and resetting the breaker.
Why does my Port A Cool Freezer motor overheat and shut off?
If your Port A Cool Freezer's motor is overheating, shutting off, and then restarting, it could be due to several reasons. One possibility is that the extension cord gauge is too small; replace it with a 12-gauge cord. Another reason might be obstructed inlet air or the unit being too close to a wall; ensure a minimum of 36 inches of inlet clearance. Finally, the motor itself could be faulty, requiring a replacement.
Why is my Port A Cool Freezer pump cycling on and off?
If the pump in your Port A Cool Freezer is cycling on and off periodically, it could be due to a few reasons. The extension cord gauge might be too small, so replace it with a minimum 12-gauge cord. Alternatively, the sump tank might be empty, so fill it with water. Lastly, the spray bar valve might be closed; open the valve.
How to troubleshoot a Port A Cool Freezer pump that won't turn on?
If the pump of your Port A Cool Freezer will not run when the switch is turned on, the issue might be with the power cord, extension cord, switches, circuit breaker, switch box, or connections. Try reconnecting the power or extension cord, resetting the breaker, or reconnecting in the switch box.
Why does the breaker trip when I turn on my Port A Cool Freezer pump?
If the breaker trips or the fuse blows when you turn on the switch of your Port A Cool Freezer, it could be due to a wiring short in the line between the pump and the switch box. You should check and replace the wiring if necessary.
Why is my Port A Cool Freezer pump motor running but the pump isn't turning?
If the pump motor of your Port A Cool Freezer is running but the pump is not turning, the issue might be with the set screws on the coupling. Try tightening the set-screw or replacing the coupling.
Why is my Port A Cool Freezer fan blade not turning and making a squealing sound?
If the fan blade of your Port A Cool Freezer doesn't turn and the unit makes a squealing sound, it could be due to a loose or broken fan belt; tighten or replace the fan belt. Alternatively, the fan pulley might be spinning on the shaft; tighten the pulley set screw.
Why does my Port A Cool Freezer pump hum but not pump water?
If the pump of your Port A Cool Freezer hums when the switch is turned on but does not pump water, it could be due to a clogged inlet filter; try cleaning the filter. Another possibility is a locked pump motor, in which case you should replace the pump. There could also be other items on the circuit; remove them.
Why is my Port A Cool Freezer overflowing or spitting water?
If your Port-A-Cool Freezer unit overflows from the sump tank or is spitting water through the fan, the float valve hose might be loose at the bulkhead fitting or at the float valve; tighten the connections and/or replace the hose washers. Alternatively, the water pressure might be too high, preventing the float valve from shutting off (50 psi max.); reduce the water pressure by checking the in-line reducer. It's also possible that the float valve isn't seating properly; check for particles in the valve and replace the float valve if needed. Finally, adjust the spray bar valve to reduce excess water flow.
General| Fan Speeds | 3 |
|---|---|
| Cooling Capacity | 1000 sq ft |
| Power Supply | 115V |
| Air Flow | 1500 CFM |
| Weight | 59 lb |
| Cooling Area | 1, 000 sq ft |
| Water Tank Capacity | 11 gal |
| Power Source | Electric |
| Coverage Area | 1000 sq ft |
Explains the principle of evaporative cooling and how it works using air as a sponge.
Describes the relationship between air humidity and the efficiency of evaporative cooling.
Details the unit's advanced features and cooling effectiveness compared to traditional coolers.
Instructions for safely removing and reinstalling cooling pads for inspection and cleaning.
Guides on proper water hose connection and electrical hookup for unit operation.
Provides essential operational specifications for various Port-A-Cool models.
Key considerations for placing the unit to ensure proper airflow and ventilation.
Step-by-step instructions for filling the unit's water sump tank.
Guides on operating the water pump and regulating flow to the cooling pads.
Instructions on how to turn on and operate the unit's fan for cooling.
Routine operational considerations for daily unit upkeep.
Steps for weekly draining, cleaning, and sump tank maintenance.
Guidance on preparing the unit for seasonal storage to prevent damage.
Guidance on identifying problems by system and understanding dependencies.
Common issues and solutions for fan motor problems in belt and direct drive models.
Common issues and solutions for water inlet, plumbing, and spray bar systems.
Detailed steps for replacing fan motors and pumps on various unit models.
Procedures for obtaining RMA numbers for warranty part returns and replacements.
Details the warranty coverage, terms, and limitations for Port-A-Cool units.
Answers common questions regarding initial assembly, setup, and storage preparation.
Addresses issues related to initial unit odors and troubleshooting cooling performance.
Discusses optimal operating environments and fan motor maintenance queries.
Information on pad replacement frequency, water supply, and moisture production.
Provides data tables showing temperature output at various relative humidity levels.
