Set Up
1. Securely fix the two hose wrap brackets to the SprayMaxx tank with the fittings provided.
2. Connect the SprayMaxx wire harness using the bullet connectors at the pump and then
connect to your 12 volt power source/battery.
3. If you would like to mount an optional boom, you can connect it by the 'boom port' on the
side of the pump.
4. Fill the SprayMaxx tank with water.
5. Before running the pump make sure the regulator is fully open to avoid premature wear or
damage to the pump. Squeeze the hand gun trigger to start discharge and then adjust the
pressure to your desired setting while keeping the gun trigger engaged.
NOTE: To maximize the pump's life, maintain pressure settings that do not cause the pump to
pulsate whenever possible.
2
4
3
5
1
