Porter-Cable 747 - To Start and Stop Saw

12
Fig. 9
A
TO PREVENT
ACCIDENTAL ELECTRICAL
SHOCK THE SAW MUST BE
HELD AS SHOWN IN FIG. 8A OR
8B, AND MUST HAVE THE
RUBBER FRONT HOUSING
COVER PROPERLY INSTALLED
AND NOT DAMAGED.
DO NOT USE THE
TOOL UNLESS THE ROTATING
HANDLE IS LOCKED IN
POSITION. IF THE HANDLE
WILL NOT LOCK THE TOOL
MUST BE RETURNED FOR
REPAIR.
TO START AND STOP SAW
1. Make sure power circuit voltage is the same as shown on the
specification plate on the saw. Connect saw to power circuit.
2. Hold saw firmly. Squeeze trigger switch (A) Fig. 9, to start motor.
Release trigger to stop motor.
Fig. 8A
Fig. 8B
A
Fig. 8C
