EMPLOYER S RESPONSIBILITIES
Employer must enforce compliance with the safety warnings and all other
instructions cont ained in this manual.
Keep this manual available for use by all people assigned to use this tool.
For personal safety and proper operation of this tool, read and follow all of
these instructions carefully.
OPERATING INSTRUCTIONS
FOREWORD
Porter-Cable Model NS100A is a heavy duty pneumatic st apler. It is designed
to inst all narrow crown (
1
… 4" wide), 18 ga. wire st aples of various lengths (from
1
… 2" to 1" long), see ACCESSORIES Listing in back of this manual.
CAUTION: Use approved Porter-Cable staples only (see ACCES-
SORIES Listing in back of this manual).
POWER SOURCE
This tool is designed to operate on clean, dry, compressed air at regulated
pressures between 70 and 120 PSI (Pounds per Square Inch). The preferred
system would include a filter, a pressure regulator , and an automatic oiler
located as close to the tool as possible (within 15 feet is ideal).
All compressed air cont ains moisture and other cont aminates that are
detriment al to internal component s of the tool. An air line filter will remove most
of these cont aminates and significantly prolong the life of the tool. If an in-line
oiler is not available: place five or six drop s of Porter-Cable Air Tool Oil (see
ACCESSORIES), into the tool s air inlet at the beginning of each workday.
The tool is equipped with a male quick connector . The tool must always be
connected to the air supply with a coupling such that all pressure is removed
from the tool when the coupling is disconnected.
CAUTION: All air line component s (hoses, connectors, filters,
regulators, etc.) must have a minimum working pressure rating of
150 PSI (10.3 BAR) or 150% of maximum system potential,
whichever is higher.
Do not connect this tool to a system with maximum potential pressure
greater than 200 PSI (13.7 BAR).
Only connect tool to air supply with a coupling that will release all
pressure from the tool when disconnected.
Disconnect tool from air supply before performing maintenance,
clearing a jammed fastener, leaving work area, moving tool to another
location, or handing the tool to another person.
TECHNICAL SPECIFICATIONS
Noise level . . . . . . . . . . . . . . . . . . . . . Typical Mean
A - W eighted sound impulse . . . . . . ef fective Acceleration . . . . . . . 2.5 m/s
2
power level . . . . . . . . . 101 dBA
P - Emission sound
pressure level . . . . . . . . 88 dBA
