Posh POS 708 - Typical Cash Drawer Wiring

POS 708 USER MANUAL Ver. 1.6
5
Figure 6: Typical Epson Cash Drawer Wiring
Figure 7: Typical Star Cash Drawer Wiring
Pin
Number
Drawer
# 1
Signal
Name
Drawer
# 2
Signal
Name
Direction
1 Frame
Ground
Frame
Ground
Ground
2 Drawer
# 1 Sink
Signal
Drawer
# 2 Sink
Signal
Input
3 + 24
VDC
+ 24
VDC
Power
4 + 24
VDC
+ 24
VDC
Power
5 Drawer
# 2 Sink
Signal
Drawer
# 1 Sink
Signal
Input
