Chapter 1: Introduction C168 Series User’s Manual
2
Chapter 1: Introduction
Printer Specifications
Mode
C168/200s
C168/300s
Printing method Thermal Transfer
Printing resolution 203 dpi (8 dots/mm) 300 dpi (11.8 dots/mm)
Max printing speed 4 ips (101.6 mm) 3 ips (76.2 mm/s)
Max printing width 4.25″(108 mm) 4.17″(106 mm)
Max printing length 157″ (4000 mm) 79″ (2000 mm)
Memory 8 MB FLASH ROM, 16 MB SDRAM
Media
Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain paper or thermal paper
Width：4.33“ (110 mm) max., 0.98” (25 mm) min.
Supply roll: OD 4″ (102 mm) max., ID 1″ (25.4 mm) min.
Thickness: 0.003″
～
0.007″ (0.08
～
0.18 mm), including liner
Ribbon
Wax, Wax/Resin, Resin
Ribbon roll: OD 3″ (76.2 mm) max., ID 1″ (25.4 mm) core
Max width: 4.33” (110 mm); Max length: 984’ (300 M)
Fonts
Five built-in dot matrix ASCII fonts, user-downloadable TrueType Fonts
Bar Code Types
1D Barcode: Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC A/E 2 and 5 add-on,
EAN-13/8/128, UCC-128.
2D Barcode: MaxiCode, PDF417, Data Matrix, QR Code.
Media sensor Reflective (Adjustable)/Transmissive
Interfaces RS-232 Serial, USB 2.0
Power rating* 24 VDC, 2.5 A
Weight 6.17lbs (2.8 kgs)
Dimensions W 9.3 x D 11.4 x H 7.8 inches (W 236 x D 291 x H 199 mm)
Operation environment
Temperature: 32° F ~ +104° F (0° C ~ 40° C)
Relative humidity: 5% - 85% non condensing
Storage environment
Temperature: -40° F ~ +140° F (-40° C ~ 60° C)
Relative humidity: 5% - 85% non condensing
Optional items Centronics Parallel Interface, 10/100Mb Ethernet, Rotary Cutter, External Rewinder, and Media Guide Adaptor
Specifications for Power Adapter
Input
AC 100~240 V, 50~60 Hz
Output
DC 24 V, 2.5 A
Environment
0° C ~ 40° C
