QRS
QUICK RELEASE SWITCH
MFG. #5471131 - REV M
2/08
PRINTED IN USA PAGE 4 OF 4
Wiring Diagram
When using the QRS as an electronic accelerator do not connect any
other initiating device to any initiating zone of the PFC-100RC. Doing
so could result in unintended operation of the dry pipe system.
The QRS uses electronic components to monitor the air pressure.
Keep all radio transmitters or RF sources at least ONE foot from the
QRS. Failure to do so could result in unintended operation of the
dry pipe system.
