Pottery Barn Canopy Bed Frame - Adding Corners and Brackets


Date:8‐Jun‐15www.potterybarn.com  Page7of12
Rev: 



5. Insert Mounting Bracket (I) to Rail (E) and Rail (F) as shown. NOTE: Screw or unscrew the small bolt on the
bracket with 2mm Allen Wrench (h) to tighten or loosen the bracket on the rail.
Attach Corner (H) to the Group (E&F) and Group (E&J). Insert Bolt (a) and tighten with 4mm Allen Wrench (f).
6. Carefully lift assembly in step 5 with 4
persons, and then attach it to the post
as shown.
h
a
a
a
a
a
a
a
a
E
E
J
J
H
H
H
H
E
F
E
F
I
I
Important Note: Make
sure the mounting
bracket side toward
the wall.

