Pottinger CAT 230 plus - Attachment; To swing mounting frame up

GB
- 7 -
9401-GB TRAKANBAU_330
TRAKANBAU
Attachement
TD 79/90/29
- Connect the Hydraulic socket gear (60) to the swivel cylinder.
- Pull out the supporting feet and secure them with the cotter
pin.
- Release hook (16) by means of the cord .
- By controlling the tractor servo-valve, lower the frame slowly.
To swing mounting frame up
Safety hints:
see supplement-A1 points 8a. - h.)
