24
KEY PART
NO. NO. DESCRIPTION
REPAIR PARTS SNOW THROWER - MODEL PR271 (96192009102)
AUGER HOUSING / IMPELLER ASSEMBLY
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
05.12.002-A
1
1
2
2
3
1 532 43 59-51 PLATE SKID PLASTIC HDPE
2 585 80 28-01 NUT LARGE FLANGE
5/16-18 – BLK
3 585 80 29-01 BOLT CARRIAGE
5/16-18 X 1.25 – BLK
To Next Page
