NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
REPAIR PARTS SNOW THROWER - - MODEL NUMBER PR621 (96182000303)
FRAME ASSEMBLY
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
1
2
2
2
5
6
06.00.001-A
4
3
1 580 85 62-01 FRAME WELDMENT
2 872 11 04-07 BOLT, CARRIAGE 1/4-20 X 7/8
3 580 50 26-01 BAR, SCRAPER UHMW
4 532 44 21-46 SCRAPER, SKIRT
5 819 09 12-16 WASHER 9/32 X 3/4 X 16 GA
6 532 19 17-30 NUT, HEX FLANGE 1/4-20 CTR
LOCK
1
2
2
06.06.001-B
1 581 02 36-01 WHEEL 7”
2 532 43 54-17 PUSH NUT
