4
9200
1) Connect the corresponding wires at the
bottom of the lamp and the motor.
2) Tighten the three screws on the edge of
the switch cover
3) Take out the decorative nuts,nuts,iron
washers and plastic washers pre-locked on
the lamp tube
4)Install glass, tighten plastic washer, iron
washer and nut in turn
5) Install the decorative frame and fasten
the decorative nut
（2）
Install the fan blades to the motor in
order and screw on the fan
blade screws in turn.(Figure 2)
3. Install the blades
4. Lamp installation
Hex nuts
Light source
chassis
light source
lampshade
（1）
Install the boom safety pin to the
junction of the boom and the
hanger.(Figure 1)
