Power Dynamics BT10SET User Manual

14
TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA
Output Power Max : 60W
Output Power RMS : 30W
Diameter Tweeter : 2”
Diameter Woofer : 5.25”
Tweeter Type : Dome
Impedance : 8Ohm
Frequency Response : 90Hz – 20kHz
SPL @ 1W/1m : 88dB
IP Rating : IPX5
Mounting Depth : 65mm
Mounting Diameter : 120mm
Power Supply : 100-240VAC 50/60Hz (15V adapter)
Power Consumption : 0.4 – 0.2A
Dimensions (L x W x H) : 85 x 45 x 25mm
Weight (kg) : 1.20
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can
be changed without prior notice.
The products referred to in this manual conform to the European Community Directives to which they are subject:
• Low Voltage (LVD) 2014/35/EU
• Electromagnetic Compatibility (EMC)
2014/30/EU
• Restriction of Hazardous Substances (RoHS) 2011/65/EU

Power Dynamics BT10SET Specifications

General

Bluetooth	Yes
Connectivity technology	Wireless
Amplifier class	D
Product color	White
Recommended usage	Home
Cables included	AC
Quantity per pack	2 pc(s)
Speaker type	2-way
Tweeter diameter	50.8 mm
Number of drivers	2
Speaker placement	In-wall/in-ceiling
Audio output channels	- channels
Mid-range driver diameter	127 mm
Number of tweeter drivers	1
Tweeter diameter (imperial)	2 \
Mid-range driver diameter (imperial)	5 \
Impedance	8 Ω
Sensitivity	88 dB
Frequency range	90 - 20000 Hz
RMS rated power	60 W
AC input voltage	100-240 V
DC input voltage	15 V
AC input frequency	50 - 60 Hz
AC adapter output current	0.4 A

Weight and Dimensions

Width	- mm
Weight	- g
