Power-Pole micro anchor Installation Manual

Mounting Options
Important: In all options it is recommended that the bottom of the MICRO Driver Unit
be mounted above the water line of the boat.
DECK MOUNT
Place bracket within 4” of edge
of mounting surface
Mark and drill holes with 5/16” drill
bit and install hardware as shown
Q
A
B
C
4”
Place bottom edge of bracket even or
higher than the boat’s water line
Mark and drill holes with 5/16” drill
bit and install hardware as shown
Q
C
B
A
TRANSOM MOUNT

Power-Pole micro anchor Specifications

General

Deployment Depth	8.5 ft
Power Source	12V battery
Control Options	Wireless remote, foot switch, Smartphone app
Mounting	Transom
Deployment Method	Electric
Power Supply	12V DC
