AUGER AND DRIVE CONTROLS
1. To engage the auger (blades), press down on the auger control lever (left side handle).
2. To engage the drive, press down on the drive control lever (right side handle). The machine should
start moving in the direction and speed for the respective setting on the speed/gear control.
3. When finished clearing a snow path, release the auger control lever (handle) and the drive control
lever (handle).
Attention: Release (disengage)
the auger and drive control lever (handles) before adjusting the drive speed control lever. NEVER
change the drive/gear speed while your snow thrower is in motion, as it will damage the drive
mechanism and void the warranty.
DRIVE SPEED/GEAR CONTROL
Move the drive speed control lever to the desired speed. There are six
(6) settings: four (4) forward
speeds and two (2) reverse speeds. 1 is the slowest forward speed and 4
is the fastest forward speed. R1 is the slowest reverse speed and R2 is
the fastest reverse speed.
Note: There is no neutral drive setting since the drive control
handle must be engaged for movement. Neutral is achieved when
the drive control handle is disengaged.
CHUTE DISCHARGE DIRECTION ADJUSTMENT
WARNING - Never direct the snow discharge chute at the operator, bystanders, vehicles or
nearby windows. Discharged snow and foreign objects accidentally picked up by the Snow
Thrower can cause serious damage and severe bodily injury. Always point the discharge
chute in the opposite direction from potential hazards. The discharge chute can be adjusted 180º by
rotating the chute rotation handle. Rotate the chute rotation handle clockwise to move the discharge chute
to the left; counterclockwise to move the chute to the right.
Auger Control
Lever (Handle)
Drive Control
Lever (Handle)
