19
Item Stock# Description Qty Item Stock# Description Qty
1 PS4006-001
Pan Head Philips screw
5 31 PS4006-031
Pan Head Philips
1
2 PS4006-002 Spindle lock cap 1 32 PS4006-032 Lower guard baffle 1
3 PS4006-003 Spring for spindle lock 1 33 PS4006-033 Nut M5 1
4 PS4006-004 Gear box cover 1 34 PS4006-034 Lower guard 1
5 PS4006-005 Spring φ0.8Xφ4 1 35 PS4006-035
Sheet steel retaining
1
6 PS4006-006 Nut M6X26 1 36 PS4006-036 Inner flange 1
7 PS4006-007
Deep groove ball
1 37 PS4006-037 TCT saw blade 1
8 PS4006-008 Big spiral bevel gear 1 38 PS4006-038 Flange nut 1
9 PS4006-009 Steel ball 3 39 PS4006-039 Outer flange 1
10 PS4006-010 Primary gear shaft 1 40 PS4006-040 Logo label 1
11 PS4006-011
Deep groove ball
4 41 PS4006-041 Screw ST4.2X12 2
12 PS4006-012 Circlip for hole 2 42 PS4006-042 Guard spanner 1
13 PS4006-013 Washer 1 43 PS4006-043 Left housing 1
14 PS4006-014 Middle axis 1 44 PS4006-044 Spring nut 1
15 PS4006-015 Big spiral bevel gear 1 45 PS4006-045 Switch knob 1
16 PS4006-016 Circlip for shaft 2 46 PS4006-046 Retaining spring 1
17 PS4006-017 Circlip for shaft 1 47 PS4006-047 Switch trigger 1
18 PS4006-018 Pinion 1 48 PS4006-048 Spring 2
19 PS4006-019 Distance tube 1 49 PS4006-049 Socket terminal 2
20 PS4006-020 Circlip for shaft 2 50 PS4006-050 Switch 1
21 PS4006-021
Deep groove ball
1 51 PS4006-051 Gear 1
22 PS4006-022 Dust port 1 52 PS4006-052
Deep groove ball
1
23 PS4006-023 Dust pipe 1 53 PS4006-053 Circlip for shaft 1
24 PS4006-024 Vacuum port 1 54 PS4006-054 O ring 1
25 PS4006-025 Pan Head Philips screw 6 55 PS4006-055
Deep groove ball
1
26 PS4006-026 Gear box 1 56 PS4006-056 Adapter sleeve 1
27 PS4006-027 Dust cover 2 57 PS4006-057 NUT M4 1
28 PS4006-028 Spindle 1 58 PS4006-058 Stator 1
29 PS4006-029 Guard cover 1 59 PS4006-059 Coil 1
30 PS4006-030
Pan Head Philips screw
M4X12(with washer)
2 60 PS4006-060 Spring washer 1
