3
CONTENTS
Technical data…...………………………………………………………. 3
Introduction …...………………………………………………………... 4
Safety information …...………………………………………………… 4
General safety rules…….……………………………………………….. 5
Special safety rules for electric mini circular saw……………………… 8
Symbols …...……………………………………………………….…… 11
Knowing your electric mini circular saw..………….….………………. 12
Assembly instruction…………………………………………….………. 13
Operating instruction…………………………………………………....... 14
Maintenance……………………………………………………..……….. 17
Exploded view& Parts list……………………………………………….. 18
Warranty statement………………………………………………………. 21
TECHNICAL DATA
Electric Mini Circular Saw Model # PS4006
Motor: 120 V, 60 Hz, 5.8 Amp
No Load Speed: 3500 rpm
Blade Diameter: 4-1/2 inch
Arbor Size: 3/8 inch
Cutting Capacity at 90°: 1-11/16 inch
Cutting Capacity at 45
°
: 1-1/8 inch
Package dimensions (L x W x H): 16.9 x 4.7 x 12.4 inches
Weight: 8.8 lb.
