Before making the final DC connection, check cable
polarity at both the battery and the Pure sine inverter.
Positive must be connected to positive; negative must be
connected to negative. Reversing the positive and nega
tive battery cables will damage the Pure sine inverter
and void your warranty.
Operation of the inverter without a proper ground
connection may result in an electrical safety hazard.
Chassis Ground (Grounding) : Ground to vehicle
chassis using #8 AWG wire.
15
HOW TO INSTALL THE DC CIRCUIT BREAKER (DC CIRCUIT
BREAKER IS NOT INCLUDED)
