CAUTION: Failure to lubricate the guide bar sprocket tip as explained
below will result in poor performance and seizure, voiding the
manufacturer’s warranty.
Lubrication of the sprocket tip is recommended after each saw use.
Always thoroughly clean the guide bar sprocket tip before lubrication.
TO LUBRICATE SPROCKET TIP:
1. Remove the battery pack from the chain saw.
2. Clean the guide bar sprocket tip.
3. Using disposable Lube gunp insert the needle nose into the
lubrication hole and inject grease until it appears at the outside
edge of the sprocket tip.
4. Turn the chain by hand. Repeat this procedure until the entire
deflection star is greased.
WARNING: Wear heavy duty work gloves when performing
this application to reduce risk of personal Injury.
NOTE: It Is not necessary to remove the chain saw to
lubricate the guide bar sprocket tip. Lubrication can be done
on the Job.
