20
iii. Use a grease gun to enlarge the grease fitting and supply the power volume of grease
as indicated below table. Grease all three pin crank bearings from the grease fittings.
Grease delivery (Pin crank bearings)
1st time 2nd time 1st time 2nd time 1st time 2nd time
4 times 4 times 5 times 5 times 7 times 7 times
SLAE03E SLAE05E SLAE05EHP
CAUTION
Use only Powerex genuine grease. Pump grease gun before using feeding (this eliminates
air from the grease passage of the extension adaptor).
Part Number: IP616200AJ (complete kit), IP600000AV (grease tube)
Notes: Each pump of the grease gun equals 0.65 g of grease.
Grease fitting
