iv. Replace the FS set and fan duct (2). Tighten bolts and nuts temporarily and confirm if
crankshaft rotates smoothly by hand and tighten them firmly. Tightening torques are as
below.
Tightening torque
First Second First Second
17 in-ib 175 in-lb 17 in-ib 265 in-lb
SLAE03E SLAE05E / SLAE05EHP
NOTE: Assemble so that dust seal and tip seal will not drop between Orbit (OS) scroll and FS scroll set.
