Inserting the battery
1. Open the battery compartment
t
on the rear side of the Multi-Purpose
Detector.
2. Place the 9 V block battery onto the contacts. Pay heed to the correct
polarity.
3. Lay the tape for removal of the battery underneath the 9 V block battery
and press it into the battery compartment
t
.
Important!
Ensure that the wires are not trapped in any way.
This would lead to irreparable damage to the appliance.
4. Close the battery compartment
t
. The battery compartment lid must close
with an audible click.
Measuring distances
1. Slide the function switch
q
to „DISTANCE“. The display
2
switches itself on.
To switch between the metric and the Anglo-American units of measurement,
press and hold the button MODE
7
. Then press the button READ
6
and
release both buttons simultaneously. When you release the buttons, the mea-
surement units change.
Note:
Measurements start at the measurement point
1
!
Should the measurement lie outside the measurement range, „Err“ or an
illogical number appear in the display. The measurement range lies between
0,6 m (2’) and 16 m (53’).
2. Hold the appliance upright towards the wall to which you wish to measure
the distance. The ultrasound sender/receiver
0
must be at a right-angle
to the wall. For this, use the spirit level: The bubble in the glass
8
must
stand between the marking lines (see Fig. 1).
3. Press the button READ
6
. The distance measured appears in the display
2
.
When you hold the button READ
6
pressed down and slowly move the
appliance over the surface to be measured, the appliance continually
measures the distances. These are shown on the display
2
.
- 5 -
