S T E P
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step.
A. Secure the lower frame to Main Frame (A) by using:
Two 75 (3/8” x 3” hex head bolt)*
Four 56 (3/8” washer)
Two 63 (3/8” nylon lock nut)
B. Install lower Flat Plate (E) into Main Frame (A) using:
Two 70 (3/8” x 2 1/2” hex head bolt)*
Four 56 (3/8” washer)
Two 63 (3/8” nylon lock nut)
C. When all parts are aligned and bolts are installed, fully tighten all fasteners.
