Assembly (Continued)
• Save all instructions
To Remove Tines
1 Remove he pins from each end of he ine shaf Refer
o Figure 3
2 Slide he four ines off he ine shaf
To Install Tines
The 4 differen ines are labeled “A” “B” “C” and “D” Refer
o Figure 4a for he loca ion of he label
For a 10” illing wid h
1 Assemble he ines as shown in Figure 4b Make sure
he collars of he ines are facing each o her
2 nser he pins in o he holes a each end of he ine shaf
o lock he ines in o place See Figure 3
For a 7” illing wid h
1 Only assemble ines B and C ( he wo inside ines) Do
no assemble ines A and D ( he wo ou side ines)
Refer o figure 4b
2 nser he pins in o he NS DE holes of he ine shaf o
lock he ines in o place See Figure 5
How to Assemble the Tines
Fig. 3
Pin
Fig. 5
Fig. 4a
D C BA
Fig. 4b
Pin
