Parts Included with Cultivator
• Middle Handle (1)
• Upper Handles (2)
• Wing nu s and bol s (4 ea )
• Spark Plug Wrench & Rod (1)
• Cable Ties (3)
• Opera or s Manual (1)
• 3 2 oz bo le of 2 Cycle engine oil (1)
* Wrench (1)
Do no opera e cul iva or if i is damaged or no securely and fully assembled
If you need assistance or find any parts
missing, CALL TOLL FREE: 1-800–737-2112
Assembly
• Save all instructions
5
WARNING
How to Unpack Cultivator from Carton
1 Remove all par s and packing componen s
2 Use a u ili y knife o cu all 4 ver ical edges Lay he side panels fla around he cul iva or
3 Remove inner componen s and packaging
CAUTION
Use care when removing par s no o damage any cables or wires ha are a ached o he par s
4 Roll he uni ou from he car on and place on a hard level surface
Fig. 2
Drag s ake
poin ed down
De en Pin
1 Place he cul iva or uprigh wi h ines and wheels on a hard level surface Wheels should be se in he lowes posi ion
WARNING
Do NOT place he cul iva or on a high surface where i can fall and cause proper y damage or personal injury
2 Assemble he middle handle o he lower handle wi h he 2 bol s and wing nu s Refer o Figure 1 Firmly hand igh en
he wing nu s
3 A ach he upper handles o he middle handle using he wo remaining bol s and wing nu s Refer o Figure 1
4 Assemble he igni ion swi ch and hro le rigger o he righ upper handle wi h he screw Use included wrench See
Figure 1
5 Make sure he igni ion wire is connec ed o bo h he igni ion swi ch (on he upper handle) and he engine Make sure
he wires are connec ed a he whi e connec ion erminal
6 Use he cable ies o secure he hro le cable and igni ion wire o he handles
7 The drag s ake is shipped wi h he poin facing upwards To use for cul iva ing remove de en pin and urn he drag
s ake upside down so he poin faces downward Re inser he de en pin Refer o Figure 2
How to Assemble the Handles and Drag Stake
Fig. 1
Lower
Handle
Middle Handle
Lef Upper
Handle
Righ Upper
Handle
Wingnu
Bol
Cable
Ties
gni ion
Wire
Thro le Wire
Screw
gni ion Swi ch
Thro le
Trigger
To Next Page
