Mode
Parameter
Default
Rang
Comment
1 2 350 10 -359
The end angles of tension release（relative down
position of angle, Need to greater than the system of
parameters【11】）
1 3 1 1 - 999
Tension release solenoid start delay timeT1（ms）
1 4 10 1 - 999
Tension release solenoid up position delay time T2（ms）
1 5 1 0／1
selection for Wiper function
0：off 1：on
1 6 10 1 - 999
Clamp /Wiper delay time ms
1 7 70 1 - 9999
Clamp /Wiper holding time ms
1 8 50 1 - 999
Clamp /Wiper revert time ms
1 9 0 0／1
Thread Clamp function：
0：off 1：on
1 A 70 0 - 359
Clamp start angle
Clamp
mode
1 B 140 0 - 359
Clamp end angle
3 1 0 0／1
The automatic test mode selection ：
0: order stitches 1: order time
3 2 300 0 ~1000
The safety SW alarm confirm time ms(the same way does not
distinguish between direct-drive safety SW and flat lock trim of
protection SW)
3 3 50 0 ~1000
The safety SW restore confirm time ms
Stop
mode
3 4 0 0／1
Motor rotation direction setup：
1：Forward 0：Reverse
motor/machine head run rate: 0.001
4 0 1000 0 - 9999
(if automatic calculation of motor/machine head run rate has
done, the Parameter value in control box maybe different with
that in HMI)
4 2 0 0 - 359
Up needle position adjusted angle（compare to up position
sensor position excursion）
4 3 175 0 - 359
Down needle position mechanical angle
Machine
head
paramete
4 4 200 0 - 800
Press down delay time(ms)
